Power rating (60Hz: VA)

Power rating (50Hz: VA)

Dimensions (OD: inch or mm)

Dimensions (H: inch or mm)

Weight: LB (kg)

No load loss (W)

Copper losses (W @20deg F or 20 deg C)

Copper losses (W @ 248 deg F or 120 deg C)

20

15

2.4 (63)

1.3 (35)

0.8 (0.38)

0.30

3.3

4.3

40

30

2.8 (74)

1.5 (39)

1.3 (0.58)

0.35

5.5

7.3

60

50

3.2 (82)

1.5 (39)

1.7 (0.78)

0.57

7.6

10.3

100

80

4.0 (105)

1.6 (40)

2.8 (1.3)

0.71

10.6

14.0

150

120

4.0 (105)

1.9 (49)

3.3 (1.5)

1.00

13.0

18.0

200

160

4.7 (120)

1.9 (49)

4.0 (1.8)

1.31

16.0

22.0

300

250

4.6 (116)

2.5 (64)

5.7 (2.6)

1.80

14.0

19.0

360

300

4.6 (116)

2.5 (64)

6.6 (3.0)

2.11

18.0

25.0

480

400

5.5 (138)

2.3 (59)

7.9 (3.6)

2.50

22.0

30.0

600

500

5.5 (138)

2.8 (72)

9.9 (4.5)

2.23

25.0

34.0

750

630

6.5 (165)

2.6 (66)

11.6 (5.3)

3.90

29.0

40

960

800

6.5 (165)

3.0 (76)

14.3 (6.5)

4.82

36.0

50

1,200

990

6.5 (165)

3.4 (86)

16.9 (7.7)

6.60

36.0

50

1,600

1,300

8.0 (202)

2.6 (65)

19.8 (9.0)

5.71

47.0

65

1,900

1,600

8.0 (202)

3.0 (75)

24.2 (11)

7.83

49.0

68

2,300

1,900

8.0 (202)

3.3 (85)

26 (11.8)

8.60

51.0

71

2,650

2,200

8.9 (227)

3.3 (85)

28.6 (13)

8.22

58.0

80

3,000

2,500

8.9 (227)

3.5 (90)

33.0 (15)

9.83

62.0

86
